CR-Series | High Power Repeaters
CR-Series combines an exceptionally high gain of 90dB with a UL/DL output power of 2W, 5W & 10W to effectively improve the quality of service and user experience in large-sized areas up to 20,000 sq meters such as office buildings, conference, supermarkets, malls, etcDescription
CR-Series Product Description
The CR-Series boosts indoor mobile signal enabling high data transmission rates and consistent signal reliability for large areas allowing operators to exploit the full 2G, 3G & 4G network capabilities.
CR- Series repeaters may also be used as a cost-efficient alternative to base stations where coverage is more critical than capacity, and no wired backbone is available.
CR-Series offers High SAW filter selectivity, provides sharp out-of-band rejection, and ensures that only the operator's frequency is amplified. Moreover, the units have a modem integrated, allowing remote control and management from our Platform Cloud Infinity.
.
Specification
Gain
90 dB
Power
2 | 5 | 10 W
Supported Technology
GSM | UMTS | LTE
Complete Network Safety Functions
Including AID, ASD, ATO and AGC.
BTO solutions can be tailored to meet customer needs.
Remote Management System
Includes Modem for Remote management via Cloud Infinity Software
Installation Sample
.png)
Remote Management System Could Infinity
Cloud Infinity is the latest platform developed by Coiler to allow customers to remotely monitor, manage, and control all the repeaters in your network.
Full access to remote surveillance and control of all the repeaters in your network. Coiler Repeater unit can be configured remotely.
Cloud Infinity map view function, you can easily visualize all the repeaters in your network.
Acknowledge and fix alarms remotely
CR-Series Portfolio
| Repeater Type | Repeater Model | Frequency -Band | Network / Technology |
Gain | Power | Bandwith |
| Single Band | CR-800 | Band 20 | LTE | 90 dB | 2W | 5W | 10W | Customized |
| Single Band | CR-900 | Band 8 | GSM UMTS LTE |
90 dB |
2W | 5W | 10W | Customized |
| Single Band | CR-1800 | Band 3 | GSM LTE |
90 dB | 2W | 5W | 10W | Customized |
| Single Band | CR-2100 | Band 1 | UMTS LTE |
90 dB | 2W | 5W | 10W | Customized |
| Dual Band | CR-809 | Band 20 | band 8 | GSM UMTS LTE |
90 dB | 2W | 5W | 10W | Customized |
| Dual Band | CR-1822 | Band 3 |Band 1 | GSM UMTS LTE |
90 dB | 2W | 5W | 10W | Customized |
| Dual Band | CR-922 | Band 8 | Band 1 | GSM UMTS LTE |
90 dB | 2W | 5W | 10W | Customized |
* Coiler design and manufacture BTO (built to order) solutions.
