CR-Series
High Power Repeaters

CR-Series
High Power Repeaters

CR-Series combines an exceptionally high gain of 90dB with a UL/DL output power of 2W, 5W & 10W to effectively improve the quality of service and user experience in large-sized areas up to 20,000 sq meters such as office buildings, conference, supermarkets, malls, etc

Device Specifications

CR-Series Product Description

The CR-Series boosts indoor mobile signal enabling high data transmission rates and consistent signal reliability for large areas allowing operators to exploit the full 2G, 3G & 4G network capabilities.

 CR- Series repeaters may also be used as a cost-efficient alternative to base stations where coverage is more critical than capacity, and no wired backbone is available.


CR-Series offers High SAW filter selectivity, provides sharp out-of-band rejection, and ensures that only the operator's frequency is amplified. Moreover, the units have a modem integrated, allowing remote control and management from our Platform Cloud Infinity.

.

Specification

Gain
90 dB

Power
2 | 5 | 10 W

Supported Technology
GSM | UMTS | LTE

Complete Network Safety Functions
Including AID, ASD, ATO and AGC.

BTO solutions can be tailored to meet customer needs.

Remote Management System
Includes Modem for Remote management via Cloud Infinity Software

Installation Sample





Remote Management System Could Infinity

Cloud Infinity is the latest platform developed by Coiler to allow customers to remotely monitor, manage, and control all the repeaters in your network.





Full access to remote surveillance and control of all the repeaters in your network. Coiler Repeater unit can be configured remotely.

.





Cloud Infinity map view function, you can easily visualize all the repeaters in your network.





Acknowledge and fix alarms remotely



CR-Series Portfolio



Repeater Type Repeater Model Frequency -Band Network /
Technology
Gain Power Bandwith
 Single Band  CR-800 Band 20  LTE  90 dB 2W | 5W | 10W  Customized

 Single Band  CR-900 Band 8   GSM
UMTS
LTE
 90 dB

2W | 5W | 10W Customized

 Single Band  CR-1800  Band 3  GSM
LTE
 90 dB 2W | 5W | 10W Customized
 Single Band  CR-2100 Band 1 UMTS
LTE
 90 dB 2W | 5W | 10W Customized
 Dual Band   CR-809 Band 20 | band 8   GSM
UMTS
LTE
90 dB 2W | 5W | 10W Customized

 Dual Band  CR-1822  Band 3 |Band 1 GSM
UMTS
LTE
90 dB  2W | 5W | 10W Customized
Dual Band  CR-922 Band 8 | Band 1 GSM
UMTS
LTE
90 dB  2W | 5W | 10W Customized

* Coiler design and manufacture BTO (built to order) solutions.
